U800 Hideaway LED Strobe Light

U800 Hideaway LED Strobe Light

The U800 LED Hideaway Strobe Light uses gen IV LEDs to produce bright light in multiple color options. Can be installed as a surface mount or as a hideaway.

Request A Quote


Powered by 12-24V

Each unit consists of 8 high intensity LEDs

16 Flash Patterns with Pattern Memory(watch the video)

Tiny Stealth Light for Head and Tail Lights

Versatile application with surface mounting design and internal mounting within light assemblies

Lifespan of up to 100,000 hours

100% Waterproof (not submersible)

Easily replaces traditional hideaway strobe with existing 1" hole

Meets or Exceeds SAE J595 Standards



5 Year Warranty on All Emergency Vehicle Lighting Products


Included in Box:

1 x LED Hide-A-Way Strobe

1 x Black Mounting Flange

1 x Rubber Gasket


Owner's Manual



⌀ 38.5mm x 18.8mm H


Interchangeable/Compatible with:

All automobiles and devices equipped with a 12 or 24 Volt DC power source.

  • LED Power: 8PCS 3W
  • Lens: /
  • LED Lifespan: 100000H
  • Flash Pattern: 16
  • Input Voltage: 12-24V
  • Max Power: 24W
  • Average Current Draw: 500mA@12.8V DC
  • Colour Available: Single color or split color
  • Ambient Temperature: -30--+70℃
  • Waterproof: IP67
  • Product Dimension: ⌀ 38.5mm x 18.8mm H
  • Mounting: Surface mount
  • Certifications: /
  • Wire: 1 pos, 1 Neg, 1 sync, 1 pattern,1 alt
  • Cable Length: 10ft (3m)
  • Material: Aluminum base
  • Net Weight: 130g
